E SERIES

E Series

Long-wheelbase platform with four to six-seat configurations.

Final configuration is confirmed against your operating requirements.

CONFIGURATION

Choose a configuration

OFFICIAL VEHICLE DATA

Dimensions, capacity, power system and chassis data below are matched to the selected seating layout.

Electric control: 48 V / 60 V / 72 V fully intelligent electric control
Battery: 100 Ah maintenance-free battery; lithium or higher-capacity battery optional
Motor: 3.5 / 4 / 5 kW AC motor options
On-board charger: Intelligent on-board charger
Charging time: 8-9 hours (from 80% discharge)
Charging input: 220V

Seats: Leather-trimmed high-resilience PU bench seats; style and color customizable
Body: Steel frame with injection-molded ABS engineering-plastic body panels
Instrument display: Instrument display with voltage readout
Rear-view mirrors: Manual exterior rear-view mirrors
Lighting and signals: LED headlamps, indicators, rear combination lamps, brake lamps and electric horn
Controls: Start, lighting and forward/reverse controls
Frame: Steel structure frame
Steering wheel: Polyurethane-foam steering wheel

Powertrain: Rear drive with continuously variable transmission
Steering system: Rack-and-pinion steering
Front axle & suspension: Semi-floating front axle
Rear axle & suspension: Integral rear axle, high-strength leaf springs and hydraulic dampers
Braking system: Four-wheel hydraulic drum brakes, dual-circuit hydraulics and parking brake
Wheels / tires: 12-inch tubeless radial tires with alloy wheels

VEHICLE FIT

Hospitality, community shuttle and longer internal routes

A long-wheelbase format focused on four-to-six passenger comfort

Discuss seating finish, roof, color and route requirements
