D SERIES

D Series

Passenger-focused configurations from two to ten seats.

Final configuration is confirmed against your operating requirements.

CONFIGURATION

Choose a configuration

OFFICIAL VEHICLE DATA

Dimensions, capacity, power system and chassis data below are matched to the selected seating layout.

Electric control: 48 V / 60 V / 72 V fully intelligent electric control
Battery: 100 Ah maintenance-free battery; lithium or higher-capacity battery optional
Motor: 3.5 / 4 / 5 kW AC motor options
On-board charger: Intelligent on-board charger
Charging time: 6-8 hours (from 80% discharge)
Charging input: 220V

Seats: Leather-trimmed high-resilience PU bench seats; style and color customizable
Body: Steel frame with injection-molded ABS engineering-plastic body panels
Instrument display: Instrument display with voltage readout
Rear-view mirrors: Manual exterior rear-view mirrors
Lighting and signals: LED headlamps, indicators, rear combination lamps, brake lamps and electric horn
Controls: Start, lighting and forward/reverse controls
Frame: Steel structure frame
Steering wheel: Polyurethane-foam steering wheel

Powertrain: Rear drive with continuously variable transmission
Steering system: Rack-and-pinion steering
Front axle & suspension: Semi-floating front axle
Rear axle & suspension: Integral rear axle, high-strength leaf springs and hydraulic dampers
Braking system: Four-wheel hydraulic drum brakes, dual-circuit hydraulics and parking brake
Wheels / tires: 12-inch tubeless radial tires with alloy wheels

VEHICLE FIT

Resorts, campuses, scenic routes and group transport

The widest range of passenger layouts in the XINYI golf series

Choose the passenger layout first, then refine colors and seating
