HERITAGE

Vintage Vehicle

Heritage-style multi-seat reception vehicle.

Final configuration is confirmed against your operating requirements.

CONFIGURATION

Compare 1 Vintage Vehicle configuration

Multi-seat01 / 06

VEHICLE SPECIFICATIONS

Available vehicle specifications

Review the listed details for this seating layout, then confirm the project configuration with our team before ordering.

Technical parameters

Maximum speed: 30km/h
Maximum gradeability: ≥30%
Braking distance: ≤5m
Minimum turning radius: 6.9m
Minimum ground clearance: 200mm
Overall dimensions (L × W × H): 4350 × 1550 × 2000mm
Driving range: ≥80km
Rated capacity: 8 people
Curb weight: 780kg

Electrical system

System voltage: 48V / 60V / 72V
Motor power: 4kW / 5kW / 7.5kW
Battery: Maintenance-free battery or lithium battery
Charger: Built-in waterproof on-board intelligent charger

Body and equipment

Seats: Bus-foam seats with high-resilience upholstery
Frame and body: Steel frame with integrated iron-shell stamped body
Paint: Automotive metallic paint
Windshield: Automotive safety glass with 3C certification
Instrument: Digital LCD panel showing voltage, speed, mileage, lighting and forward/reverse status
Lighting and signals: Combination headlights, turn signals, rear lamps, brake lamps and electric horn
Switches: Start, lighting, parking-position and forward/reverse switches
Audio and camera: Vehicle radio with reversing-camera all-in-one display
Wire harness: National-standard waterproof, flame-retardant automotive harness

Chassis and running gear

Power transmission: Continuously variable speed system with climbing function
Steering system: Rack-and-pinion steering gear
Front and rear suspension: Front and rear semi-floating suspension systems
Braking system: Four-wheel drum brakes, dual-loop hydraulic braking and parking brake
Tyres: Highway-specific 165R13 tyres with aluminium hubs

Specifications apply to the selected configuration. Where no unit is shown, confirm it before ordering. Confirm charging input, battery specification and final performance for your destination and configuration.

VEHICLE FIT

Designed around the work

Best for

Hotels, event venues, heritage districts and VIP reception

Key advantage

Heritage-inspired styling that creates a memorable arrival

Configuration support

Coordinate exterior colors and interior trim with the venue

Compare every configuration in this series

Compare seating layouts against your route. Select a configuration to view its matched gallery and complete specifications.

Vintage Vehicle / Multi-seat

Capacity: Multi-seat

Overall dimensions (L × W × H): 4350 × 1550 × 2000mm
Driving range: ≥80km
Battery: Maintenance-free battery or lithium battery

We welcome inquiries worldwide. Include your destination, charging setup, operating use and quantity to discuss the right configuration for your project. Read the purchasing checklist →
